The NG-05R Automatic Mattress Rolling Machine(Fixed Diameter) automatically rolls compressed mattresses to a consistent, fixed diameter — ideal when you need uniform rolls for stable packing, palletizing and shipping. Built for continuous production, it delivers repeatable results with simple operation and low maintenance.
Product description
The NG-05R is a high-performance automatic rolling machine designed specifically for roll-packing foam and compressed mattresses with a fixed diameter. It offers a reliable and efficient solution for manufacturers seeking to streamline their packaging process, reduce shipping volume, and improve logistics handling.
With its automated operation, user-friendly control panel, and robust build, the NG-05R ensures consistent rolling results — ideal for standard-size packaging across production batches.
Technical Specification
|
Mattress Size |
L2000*W1800*H[50-250] MM |
|
Working Table Width |
2060MM |
|
Rolling Exit Diameter： Fixed |
(Can choose one diameter of them) 200、230、268、290、320、370、400、450MM |
|
Efficiency |
1 MIN/PCS |
|
Pushing Power |
3.7KW |
|
Rolling Power |
5.5KW / 7.5KW [450MM diameter] |
|
Transfer Power |
1.5KW |
|
Enter Power |
0.75KW |
|
Machine Total Power |
12.15KW / 14.15KW [450MM diameter] |
|
Weight |
2.5 Tons |
|
Voltage |
3 Phases 380V/50HZ (Customized) |
|
Machine External Size |
L4300*W2600*H1350MM |
Product advantages
1. Suitable for roll packing pure latex mattresses or sponge mattresses especially. For thick mattresses or spring mattresses, it is recommended to be compressed before using the device for rolling.
2. High production efficiency and simple operation; simply place the mattress and bag, press a button, and the operation can be completed automatically.
3. Low cost of packaging consumables;each mattress only requires a PVC or PE bag with a diameter of about 320mm.
4.Greatly reduce mattress transportation and storage costs; after rolling, the volume of the mattress is greatly reduced.
4. Compact and comcise overall structure, with a small footprint.
5. CE certification, high safety, stable performance, and convenient installation and maintenance.
